ISO 10BBL 2 Vessel Micro Brewhouse Fired Direct Heating For Beer Brewery Plant
Quick Details
1. Products: 10BBL brewhouse
2. Capacity: 1000L
3. Heat Method: Fired direct heating
4. Material: sanitary stainless steel SUS304 SS316L
5. Function: beer brew
6. Over 10years strong factory
7. Customized service
Feature Of 10BBL Beer Brewhouse System
| NO. | MAIN SYSTEMS | EQUIPMENTS&PARTS | SPECIFICATIONS | QTY |
| A | Malt Milling System | Malt Mill | 500-800kg/hr, 3kw, malt particle size is adjustable | 1 |
| Grist Feeder | Capacity 1200L, 1.5KW/60HZ motor, speed is adjustable | 1 |
| B | Mash System
2 Vessels Brewhouse | Mash/Lauter Tun | 1000L, 2.2KW/60HZ motor, Speed is 0~60 r/min by inverter | 1 |
| Boil Kettle/Whirlpool Tun | 1000L | 1 |
| Wort grant | 20L,Glass wort grant | 1 |
| Plate Heat Exchanger | 18m2,2 stages | 1 |
| Working Platform | Dismountable,SS304 | 1 |
| Valves and Pipeline | 1 set | 1 |
| Wort pump | 3T/hr,Sanitary SS304, Pump lift-24m | 2 |
Control System
Selectable | Manual | 1 |
| Semi-Auto by PLC | 1 |
| C | Fermentation System | Beer Fermenter | Usage: For beer fermentation
Jacketed and insulated Stainless steel beer fermenter with 60 degree conical bottom, working capacity:10HL, head space:25%.
lMaterial: SS304, 3A mirror polished interior shell
lThickness: Interior shell-3mm; Dimple jacket-2mm; Exterior shell-2mm; Insulation-50mm PU
lGeneral accessories: 1.Swing out manhole at side ; 2. CIP spraying Ball; 3.Adjustable feet; 4.Temperature sensor; 5. Sample valve; 6. Inlet, beer racking arm outlet and yeast drain; 7. lift lugs; 9. Support: 3 stainless steel legs; 10.Top 100mm hop port;11.Pressure Safty Valve. | 6 |
| D | Maturation/Storage | Bright Beer Tank | Usage: For beer conditioning
Jacketed and insulated Stainless steel beer bright tank, working capacity:10HL, head space:25%.
lMaterial: SS304, 3A mirror Polished inner tank.
lThickness: Interior shell-3mm; Dimple jacket-2mm; Exterior shell-2mm; Insulation-50mm PU
lGeneral accessories: 1. Swing out Manhole at side; 2. CIP spraying Ball ;3. Adjustable feet; 4. Temperature sensor; 5. Sample valve; 6. Inlet, beer outlet; 7. Pressure Safety Valve; 8. lift lugs; 9. Support: 3 stainless steel legs. | 2 |
| E | Hot&Cold Water System | Hot Liquor Tank | Stainless steel, Dimple heating jacket, effective capacity is 20HL,Manhole at top, Sight gauge for water level and Insulated, with rotating sparging ball. | 1 |
| Cold Liquor Tank | Stainless steel, Dimple cooling jacket , effective capacity is 20HL,Manhole at top, Sight gauge for water level and Insulated, with rotating sparying ball. | 1 |
| Water Pump | 3m3/hr, Sanitary SS304, Inverter Control, Pump Lift-24m | 1 |
| F | Glycol Cooling System | Glycol Chiller | Cooling capacity: 11008Kcal/h (12.8KW); Compressor power: 3.14KW×2 (Panasonic); Water pump power: 0.75KW; Dimension: 1320×720×1320mm | 1 |
| Water Pump | 1T/hr, Sanitary SS304,Pump lift:-24m | 1 |
| Glycol Storage Tank | 500L for Glycol Storage | 1 |
| G | Cleaning System | Portable CIP | 300L with 2 sets of 1.5kw water pumps | 1 |
Method of Heating Ways:
-
Steam: Dimple plate jacket with inlet/outlet fittings for Steam heat transfer;
-
Electric: Use electric heaters in jacket to heat the medium in the jacket
-
Gas fired: Use gas burner at bottom to heat tank directly;
Description
To make the best beer possible, the brew house is the key. On the basis of absorbing European advanced and experienced beer machinery technology, Our Brew house can fulfill various brewing technologies, variable tastes or specific capacities.
10BBL | 20BBL | 30BBL | 40BBL | 50BBL brewhouse sizes are produced standardly, or even larger for customers. The Brew house can be heated with Steam, Gas fired, Electric etc. The system composed of Mash Tun , Lauter Tun, Brew Kettle, Whirlpool Tank etc. The four tanks can be combined together to meet different requirement of brew system.
All the tanks certified stainless steel material for all tanks, with 100% TIG welded joints and seams with sanitary interior polish. All tanks use Tri-clamp connections, are designed for up to 14.7 PSI and tested at 30 PSI. We can custom fabricate any tank to meet your brewery’s space and height restrictions.
Application
Micro Brewhouse 2bbl 3bbl 5bbl 7bbl 10bbl beer brewing equipment produced by us. the brewhouse equipment for the production of live and filtered beer, brew master make their beer attractive to comsumers by unique brewing process and distinctive beer taster. If desired, they can be placed directly in places of consumption of beer: restaurants, pub, bars, hotels, tourist and shopping centers.
